High Quality uav ground control station XK-G25
$5,714
UAV ground control station Features
Full body aluminum alloy shell+silicone anti slip, higher protection
Dual 15.6-inch 1000nit outdoor visual screen
lntel15/17 High Performance CPU
Up to RTX3060 independent display support
18 physical channel outputs, dual SBUS, and USB-HID outputs
Touch pad with left and right buttons+86 key standard keyboard
Supports the installation of most data links on the market
Coulomb meter precise battery management, low battery reminder, and low battery automatic shutdown
Uav Ground Control Station XK-G25
1. The entire machine is made of aluminum alloy, using silicone anti slip technology and equipped with 8 anti-collision corners for higher protection
2. Dust and splash prevention measures are taken at all external device interfaces to ensure equipment safety.
3. Dual 15.6-inch 1000nit touch screen outdoor visual large screen
4. Touch pad with left and right buttons+86 key standard keyboard
5. Configure 18 physical channels, support dual serial port data transmission and dual SBUS output
6. It can support custom network segments, better compatibility with various cameras, gimbals, pods and other video devices, support HDMI video output, facilitate the expansion of large screen display
7. Support working in low and high temperature environments to reduce equipment damage in extreme weather conditions
8. Coulomb meter precise battery management, low battery reminder and automatic low battery shutdown
9. Flight control data connection supports USB connection, LAN connection, serial port connection, etc.
10. It can support up to RTX3060 independent display
Technical Parameters
| Product Parameter | Model | G25 |
| Case Material | Aluminum Alloy | |
| Anti-vibration | Chassis with 8 shock-absorbing silicone pads | |
| Color | Gunmetal Gray | |
| CPU | Intel I7 | |
| Memory | 16G | |
| Storage | 256GB SSD | |
| Graphics | Intel 620 Integrated | |
| Keyboard | Standard Keyboard | |
| Mouse Touchpad | with left and right mouse buttons | |
| Network | 1 Gigabit Ethernet port | |
| System | Windows 10 | |
| Screen Size | 15.6 inch | |
| Resolution | 1920*1080 | |
| Brightness | 1000nit | |
| Battery Life | 4-5 hours | |
| Battery Level Display | PC System Display/Led Battery Level | |
| Weight | 10KG | |
| Storage temperature | -20-65ºC | |
| Working temperature | -10-45ºC | |
| External Interface | USB*4, LAN*1,DC IN, | |
| Joystick mode | Dual S-BUS 18 channels/ USB-HID | |
| Rocker | 2*Flying rocker 1*Thumb rocker (customizable) | |
| Toggle | 8*Three-speed toggle/2*Two-speed toggle(can be customized)) | |
| Knob | 2*potentiometer knob (customizable) | |
| Adjustment mode | Upper computer |
